SFP Modules

SFP Modules SFP-MM2-D

Optical SFP module with DDM. 100Base-FX, 2 multi-mode fibers, 1310nm, 12dB optical budget, 0~2Km range, duplex LC connector.

Ref. SFP-MM2-D Categories: , Tags: , ,

Description

Optical SFP module with DDM. 100Base-FX, 2 multi-mode fibers, 1310nm, 12dB optical budget, 0~2Km range, duplex LC connector.

The KBC SFP module range provides true flexibility to the KBC range of media converters and Ethernet Switches. Optical modules include Digital Diagnostics Monitoring (DDM) KBC SFPs are compatible with KBC entire range of switches and media converters.

If you need a SFP with some other features that you can’t find on our site, please consult us, we have more than the ones listed here.

Features:

  • 10,100,1000 and 10000 options available
  • Distances from 100m up to 80km
  • Single and duplex Multimode or Singlemode options
  • LC, SC and RJ45 options
  • IEEE – 100/1000BASE-T/SX/LX/XD/ZX/FX ad 10GBase-FX
  • Temperature hardened -40°C ~ +74°C

Specifications

Data Rate

    • 100Base-FX

Type of Transmission media:

    •  2 multi-mode fibers

TX λ/RX λ:

    • 1310nm/13010nm

Connectors

    • Duplex LC

Accesories

If you need some information about related accessories, please consult us.

Video

Video not available

Downloads

Datasheet of  SFP Modules
