Photoelectric Reflector Beam PR-11B

The PR-11B Reflector Beam is suitable for both indoor and outdoor use, for applications where a beam-break is desirable but running cable to both ends is impractical. A convenient way to monitor entrances, gateways, and driveways – for general monitoring and lighting control.

Ref. PR-11B Categories: , Tags: , , ,

Description

The PR-11B Reflector Beam is suitable for both indoor and outdoor use, for applications where a beam-break is desirable but running cable to both ends is impractical. A convenient way to monitor entrances, gateways, and driveways – for general monitoring and lighting control.

Outdoor 1-11m (3.3-36ft) or less Indoor 1-15m (3.3-49ft) or less

Features:

  • Easy Installation
  • Suitable for both indoor and outdoor use
  • Double Modulated Beam for unsurpassed Light Immunity
  • 50,000 lux sunlight immunity
  • Monitor jack for alignment with multi-meter
  • Beam direction can be rotated a full 180 degrees
  • Response time adjustment

Specifications

  • Model: PR-11BE
  • Product type: Photoelectric Beam Sensor
  • Detection system: Near infrared beam interruption system (reflective).
  • Protection distance: Outdoor 1-11m (3.3-36ft) or less | Indoor 1-15m (3.3-49ft) or less
  • Supply voltage: 10,5 V to 30 VDC (Non-polarity)
  • Current consumption: 55mA or less
  • Alarm output: Dry contact relay NO/NC- Contact action : Interruption time (minimum 2 seconds)- Contact capacity : 30V AC/DC, 0.5A or less
  • Tamper output: Dry contact relay N/C – Action : Activated when cover is detached – Contact capacity : 30V AC/DC, 0.5A or less
  • Response Time: 0.05sec to 0.7sec (adjustable by potentiometer)
  • Alarm LED: Red LED | ON : when an alarm is initiated.
  • Attenuation LED: Red LED | ON : when beam is attenuated.
  • Functions: Monitor output
  • Ambient temperature range: -25°C to +60°C (-13°F to +140°F)
  • Mounting positions: Indoor / Outdoor
  • Wiring: Terminals
  • Weight: Sensor : 430g (15oz) | Reflector : 490g (17oz)
  • Appearance: Sensor : PC resin (wine red)- Reflector : acrylic resin (clear), AES resin (black)

Accesories

If you need some information about related accessories, please consult us.

Downloads

Datasheet PR-11B TAKEX

Manual PR-11B TAKEX
